Products > Crystallization Plates, Hardware & Accessories > 24 Well Crystallization Plates > VDXm Plate with sealant

VDXm Plate with sealant

Applications

  • Hanging drop crystallization

Features

  • 24 well plate with raised cover
  • Sealant applied to 24 wells, ready to seal with cover slides
  • Compatible with 18 mm diameter circle cover slides
  • Optically clear plastic
  • 128 mm x 85 mm microplate footprint
  • Compatible with UV crystal imaging when used with HR3-239 and HR3-241 – 18 mm x 0.22 mm Siliconized circle cover slides

Description

24 well plate with sealant for hanging drop vapor diffusion crystallization with a 128 mm x 85 mm microplate footprint. Stackable, optically clear plastic, 24 well plates with raised covers (to allow room for cover slides) and flat bottoms for exceptional optics. Raised, wide rings around each reservoir (well) minimize cross contamination and allow each well to be individually sealed with 18 mm diameter circle cover slides. Plates are individually wrapped and supplied with applied sealant.

The microplate footprint is space-saving and compatible with automated liquid handling systems.

Approximate dimensions: 128 mm x 85 mm.
Approximate well ID: 14.4 mm.
Typical well volume: 100 to 500 µl.
Height with cover 19.5 mm.
Height without cover with 18 x 0.22 mm cover slide 16 mm.
Height without cover with 18 x 0.96 mm cover slides 17 mm.

Show More



VDXm Plate with sealant

Click to Zoom In

VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant

VDXm Plate with sealant

Click to Zoom In

VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant
VDXm Plate with sealant

CAT NO

HR3-306

NAME

VDXm™ Plate with sealant

DESCRIPTION

50 plate case

PRICE

$284.00

cart quote

Related Item(S)

  • OptiClear Plastic Cover Slides
  • 18 mm Siliconized Glass Cover Slides

References

1. Expression and crystallization of DsbA from Staphylococcus aureus. J.L. Martin et al. Acta Cryst. (2007). F63, 953-956.
